21-9
Cisco IE 3000 Switch Software Configuration Guide
OL-13018-01
Chapter 21 Configuring IGMP Snooping and MVR
Configuring IGMP Snooping
Configuring a Multicast Router Port
To add a multicast router port (add a static connection to a multicast router), use the ip igmp snooping
vlan mrouter global configuration command on the switch.
Beginning in privileged EXEC mode, follow these steps to enable a static connection to a multicast
router:
To remove a multicast router port from the VLAN, use the no ip igmp snooping vlan vlan-id mrouter
interface interface-id global configuration command.
This example shows how to enable a static connection to a multicast router:
Switch# configure terminal
Switch(config)# ip igmp snooping vlan 200 mrouter interface gigabitethernet1/2
Switch(config)# end
Configuring a Host Statically to Join a Group
Hosts or Layer 2 ports normally join multicast groups dynamically, but you can also statically configure
a host on an interface.
Beginning in privileged EXEC mode, follow these steps to add a Layer 2 port as a member of a multicast
group:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip igmp snooping vlan vlan-id mrouter
interface interface-id
Specify the multicast router VLAN ID and the interface to the
multicast router.
• The VLAN ID range is 1 to 1001 and 1006 to 4094.
• The interface can be a physical interface or a port channel.
The port-channel range is 1 to 6.
Step 3
end Return to privileged EXEC mode.
Step 4
show ip igmp snooping mrouter [vlan vlan-id] Verify that IGMP snooping is enabled on the VLAN interface.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip igmp snooping vlan vlan-id static ip_address
interface interface-id
Statically configure a Layer 2 port as a member of a multicast
group:
• vlan-id is the multicast group VLAN ID. The range is 1 to
1001 and 1006 to 4094.
• ip-address is the group IP address.
• interface-id is the member port. It can be a physical
interface or a port channel (1 to 6).
Step 3
end Return to privileged EXEC mode.
