2-119
Cisco ME 3800X and ME 3600X Switch Command Reference
OL-28238-01
Chapter 2 Cisco ME 3800X and ME 3600X Switch Cisco IOS Commands
ip sla
Examples In the following example, operation 99 is configured as a UDP jitter operation in an IPv4 network and
scheduled to start running in 5 hours. The example shows the ip sla command being used in an IPv4
network.
Switch(config-term)# ip sla 99
Switch(config-ip-sla)# udp-jitter 172.29.139.134 dest-port 5000 num-packets 20
Switch(config-ip-sla)# ip sla schedule 99 life 300 start-time after 00:05:00
Note If operation 99 already exists and has not been scheduled, the command line interface will enter IP SLA
configuration mode for operation 99. If the operation already exists and has been scheduled, this
command will fail.
Related Commands
Command Description
ip sla group schedule Configures the group scheduling parameters for multiple IP SLAs
operations.
ip sla
reaction-configuration
Configures certain actions to occur based on events under the control
of IP SLAs.
ip sla reaction-trigger Defines a second IP SLAs operation to make the transition from a
pending state to an active state when one of the trigger action type
options are defined with the ip sla reaction-configuration command.
ip sla schedule Configures the scheduling parameters for a single IP SLAs operation.
show ip sla configuration Displays configuration values including all defaults for all IP SLAs
operations or the specified operation.
show ip sla statistics Displays the current operational status and statistics of all IP SLAs
operations or a specified operation.
show ip sla statistics
aggregated
Displays the aggregated statistical errors and distribution information
for all IP SLAs operations or a specified operation.
