CHAPTER 11
Configuring Online Diagnostics
This chapter contains the following sections:
• Information About Online Diagnostics, on page 115
• Configuring Online Diagnostics, on page 117
• Verifying the Online Diagnostics Configuration, on page 118
• Default Settings for Online Diagnostics, on page 118
Information About Online Diagnostics
Online diagnostics provide verification of hardware components during switch bootup or reset, and they
monitor the health of the hardware during normal switch operation.
Cisco Nexus Series switches support bootup diagnostics and runtime diagnostics. Bootup diagnostics include
disruptive tests and nondisruptive tests that run during system bootup and system reset.
Runtime diagnostics (also known as health monitoring diagnostics) include nondisruptive tests that run in the
background during normal operation of the switch.
Bootup Diagnostics
Bootup diagnostics detect faulty hardware before bringing the switch online. Bootup diagnostics also check
the data path and control path connectivity between the supervisor and the ASICs. The following table describes
the diagnostics that are run only during switch bootup or reset.
Table 22: Bootup Diagnostics
DescriptionDiagnostic
Tests PCI express (PCIe) access.PCIe
Verifies the integrity of the NVRAM.NVRAM
Tests connectivity of the inband port to the supervisor.In band port
Tests the management port.Management
port
Verifies the integrity of the DRAM.Memory
Cisco Nexus 3548 Switch NX-OS System Management Configuration Guide, Release 7.x
115
