2.10.1 RTRV-PM-<MOD2>
2.10.1 RTRV-PM-<MOD2>
The RTRV-PM-<MOD2> command retrieves the RMON-managed PMs.
The TL1 modifiers FSTE/GIGE/POS are used to retrieve the RMON-managed Ethernet PM, if the
Ethernet port is a FSTE/GIGE/POS port type. The FC modifier retrieves the RMON-managed Fibre
Channel PM.
There are three accumulation time periods for RMON statistics: 1-MIN, 1-HR, and RAW-DATA. For
RMON-managed PMs, only history PM buckets and RAW-DATA are supported and there is no current
bucket defined for RMON-managed PMs. When RAW-DATA is specified in the input of RTRV-PM, the
date and time specified in the input will be ignored. The mondate and montime in the output will be the
last time the counters were cleared. RAW-DATA will be the default TMPER value for RMON-managed
PM retrieval.
Because RMON PM only supports the history data if the accumulation time period is 1-MIN, 15-MIN,
1-HR, or 1-DAY, you must specify the correct history PM bucket for the RTRV-PM command to succeed.
When retrieving PM, if an unsupported montype is specified, an error message will be returned.
Currently there is no support of LOCN (location) and DIRN (direction) for RMON-managed data
statistics.
Input Format RTRV-PM-<MOD2>:[<TID>]:<AID>:<CTAG>::[<MONTYPE>],[<MONLEV>],[<lSTM>],
[<DIRECTION>],[<TMPER>],[<DATE>],[<TIME>];
Input Example RTRV-PM-GIGE:TID:FAC-2-1:123::ETHERSTATSOCTETS,,,,1-MIN,04-11,12-45;
RTRV-PM-GIGE:TID:FAC-2-1:123::,,,,RAW-DATA;
Output Format SID DATE TIME
M CTAG COMPLD
“<AID>,[<AIDTYPE>]:<MONTYPE>,<MONVAL>,[<VLDTY>],[<LOCN>],
[<DIRECTION>],[<TMPER>],[<MONDAT>],[<MONTM>]”
;
Output Example TID-000 1998-06-20 14:30:00
M 001 COMPLD
“FAC-2-1,GIGE:etherStatsOctets,21,COMPL,,,1-MIN,04-11,12-45”
;
Table 2-11 shows the error messages associated with the RTRV-PM-<MOD2> command.
