Chapter 2 Procedures and Provisioning
2.2.2 TAP Creation and Deletion
2.2.2.5 ED-STSn
When the ED-STSn command is issued for a TACC it assigns the STS for the first two-way test access
connection and STS+1 as the second 2-way connection. For STS3c, STS9c, STS12c, STS24c, and
STS48c the next consecutive STS of same width is chosen. The TAP creation will fail if either of the
consecutive STSs are not available.
The command in Example 2-4 creates a TAP on STS-5-1 and STS-5-2.
Example 2-4 ED-STS1::STS-5-1:12:::TACCC=4
DV9-99 1970-01-02 03:16:11
M 12 COMPLD
;
Note These STSs cannot be used for the creation of cross-connects until the TAP is deleted.
The command in Example 2-5 creates an STS24C dual TAP on STS-6-1 and STS-6-25.
Example 2-5 ED-STS24C::STS-6-1:12:::TACC=5:
DV9-99 1970-01-02 03:16:11
M 12 COMPLD
;
Note These STSs cannot be used for the creation of cross-connects until the TAP is deleted.
2.2.2.6 ED-VT1
When the ED-VT1 command is issued for a TACC, a VT TAP is created. The specified VT AID is taken
as the first VT connection, the second VT connection is made by incrementing the VT group and keeping
the VT number the same.
The command in Example 2-6 creates a VT TAP on VT1-1-1-1-1 and VT1-1-1-2-1.
Example 2-6 ED-VT1-1-1-1-1:12:::TACC=6;
DV9-99 1970-01-02 03:16:11
M 12 COMPLD
;
Note These VTs cannot be used for the creation of cross-connects until the TAP is deleted.
