2.4.10 1-Way Drop and Continue
2.4.10 1-Way Drop and Continue
The following examples show how to create a 1-way drop and continue cross-connect. The examples use
three nodes (Node 1, Node 2, and Node 3) in a ring configuration (Figure 2-46). Node 1 is the source
node, Node 2 has the drop and continue, and Node 3 is the destination.
Figure 2-46 1-Way Drop and Continue
6/1/1
East
5/1/1
West
6/1/1
East
5/1/1
West
6/1/1
East
5/1/1
West
1/1/1
Source Node
1/1/1
Drop and Continue Node
1/1/1
Destination Node
Node 2 Node 3
Node 1
