2-18
Cisco ONS SONET TL1 Command Guide, R6.0
Chapter 2 Procedures and Provisioning
2.2.9 Test Access Mode Definitions
Figure 2-12 SPLTE Access Single TAP
Figure 2-13 SPLTE Access Dual TAP
2.2.9.5 SPLTF
Split F (SPLTF) splits both the A and B paths and connects the F side of the accessed circuit to the FAD
(Figure 2-14 and Figure 2-15).
Note QRS is not supported on the ONS 15454, ONS 15327, and ONS 15310-CL. The connection will remain
as is. The ONS 15600 inserts AIS instead of QRS.
Figure 2-14 SPLTF Access Single TAP
102058
A
E
B
F
"Mapped"
AID
AID
Single TAP
QRS
61110
A
E
B
F
"Mapped"
AID
AID
Dual-FAD TAP
(2 times the bandwidth
of the circuit accessed)
BB
102057
A
E
B
F
"Mapped"
AID
AID
Single TAP
QRS
