2-71
Cisco ONS SONET TL1 Command Guide, R6.0
Chapter 2 Procedures and Provisioning
2.12.3 OC-N Payload Provisioning Parameters
The configuration parameters for OCn ports can be retrieved/edited using the ED-<OCN_TYPE> and
RTRV-<OCN_TYPE> commands. The following is a list of restrictions when using the
ED/RTRV-<OCN_TYPE> command parameters:
• DCC/LDCC parameters are used to enable/disable SDCC/LDCC functionality respectively.
• Synchronization parameters are applicable only to cards supporting synchronization:
MXP-2.5G-10G, TXP-MR-10E, and MXP-2.5G-10E. Only SYNMSG and SENDDUS parameters
are supported.
• Signal fail/signal degrade can be provisioned using SDBER and SFBER parameters respectively.
• Soak time and administrative/service state parameters can be provisioned using, SOAK,
SOAKLEFT, PST, SST and CMDMDE parameters.
• The SONET/SDH selection can be provisioned using the MODE parameter.
• The name of the facility can be provisioned using the NAME parameter.
• The J0 section parameters can be provisioned using the EXPTRC, TRC, INCTRC, TRCMODE and
TRCFORMAT parameters.
MXP_2.5G_10E OC48 DWDM-SECTION, DWDM-TRANS-AIS,
DWDM-TRANS-SQUELCH
MXP_MR_2.5G AND
MXPP_MR_2.5G
Port-1: 1GFC, 1GFICON,
GIGE
Port-2: 1GFC, 2GFC,
1GFICON, 2GFICON,
GIGE
1
FCGE
2
1. If 2GFC or 2GFICON is on Port-2, then Port-1 must be unprovisioned. If Port-1 is provisioned then Port-2 cannot contain
2GFC or 2GFICON because of bandwidth limitations. Ports 3 through 8 are not available. ESCON payload is not supported.
2. ESCON and mixed card modes are not supported.
Table 2-18 Payload/Card Mode Support (continued)
Card Type Payload Card Mode
