Cisco RV042G Administration Guide

Configuring a Gateway-to-Gateway VPN Tunnel Between RV0xx Series Routers
Configuring a VPN Tunnel on a Cisco RV0xx Series Router
Cisco Small Business RV0xx Series Routers Administration Guide 180
D
Local Security
Group Type
Subnet
IP Address 192.168.1.0
Subnet Mask 255.255.255.0
Remote Group Setup
Remote Security
Gateway Type
Dynamic IP + Domain Name (FQDN) Authentication
Domain Name cisco.com
Remote Security
Group Type
Subnet
IP Address 192.168.2.0
Subnet Mask 255.255.255.0
IPSec Setup
Keying Mode IKE with Preshared Key
Phase 1
Encryption
DES
Phase 1
Authentication
MD5
Phase 1 SA Life
Time
28800
Perfect Forward
Secrecy
Enabled
Phase 2 DH
Group
Group 1 - 768 bit
Phase 2
Encryption
DES
Phase 2
Authentication
MD5
Field Value

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
