Configuring a Gateway-to-Gateway VPN Tunnel Between RV0xx Series Routers
Configuring a VPN Tunnel on a Cisco RV0xx Series Router
Cisco Small Business RV0xx Series Routers Administration Guide 181
D
Settings on the Site B Router:
Phase 2 SA Life
Time
3600
Preshared Key 13572468#123456789
Minimum
Preshared Key
Complexity
Enabled
Advanced Default settings
Field Values
Local Group Setup
Local Security
Gateway Type
Dynamic IP + Domain Name (FQDN) Authentication
Domain Name cisco.com
Local Security
Group Type
Subnet
IP Address 192.168.2.0
Subnet Mask 255.255.255.0
Remote Group Setup
Remote Security
Gateway Type
IP Only
IP Address 203.165.200.226
Remote Security
Group Type
Subnet
IP Address 192.168.1.0
Subnet Mask 255.255.255.0
Field Value

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
