VLAN Management
Defining VLAN Membership
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 165
12
STEP 5 Click Apply. The parameters are written to the Running Configuration file.
Defining VLAN Membership
The
Port to VLAN
and Port VLAN Membership pages display the VLAN
memberships of the ports in various presentations. You can use them to add or
remove memberships to or from the VLANs.
When a port is forbidden default VLAN membership, that port is not allowed
membership in any other VLAN. An internal VID of 4095 is assigned to the port.
To forward packets properly, intermediate VLAN-aware devices that carry VLAN
traffic along the path between end nodes must be manually configured.
Untagged port membership between two VLAN-aware devices with no
intervening VLAN-aware devices, should be to the same VLAN. In other words, the
PVID on the ports between the two devices must be the same if the ports are to
send and receive untagged packets to and from the VLAN. Otherwise, traffic might
leak from one VLAN to another.
VLAN-tagged frames can pass through VLAN-aware or VLAN-unaware network
interconnection devices. If a destination end node is VLAN-unaware, but is to
receive traffic from a VLAN, then the last VLAN-aware device (if there is one), must
send frames of the destination VLAN to the end node untagged. That is, the egress
port that reaches the end node must be an untagged member of the VLAN.
Configuring Port to VLAN
Use the
Port to VLAN
page to display and configure the ports within a specific
VLAN.
To map ports or LAGs to a VLAN:
STEP 1 Click VLAN Management > Port to VLAN. The
Port to VLAN
page opens.
STEP 2 Select a VLAN and the interface type (Port or LAG), and click Go to display or to
change the port characteristic with respect to the VLAN.
