Cisco SF200-24 User Manual

Configuring Quality of Service
Configuring QoS - General
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 260
18
STEP 3 Click Apply. The queues are configured, and the Running Configuration file is
updated.
Mapping CoS/802.1p to a Queue
The CoS/802.1p to Queue page maps 802.1p priorities to egress queues. The
CoS/802.1p to Queue Table determines the egress queues of the incoming
packets based on the 802.1p priority in their VLAN Tags. For incoming untagged
packets, the 802.1p priority will be the default CoS/802.1p priority assigned to the
ingress ports.
Default Mapping Queues
By changing the CoS/802.1p to Queue mapping and the Queue schedule method
and bandwidth allocation, it is possible to achieve the desired quality of services
in a network.
CoS/802.1p to Queue mapping is applicable only if CoS/802.1p is the trusted
mode and the packets belong to flows that are CoS trusted.
802.1p
Values
(0-7, 7 being
the highest)
Queue
(4 queues 1-
4, 4 being the
highest
priority)
Queue
(2 queues:
Normal and
High)
Notes
0 1 Normal Background
11 NormalBest Effort
2 2 Normal Excellent Effort
3 3 Normal Critical Application
LV S p h o n e S I P
43 Normal Video
54 High Voice
Cisco IP phone default
64 High Interwork Control
LVS phone RTP
74 High Network Control

Cisco SF200-24 Specifications

General

Model	SF200-24
Switching Capacity	8.8 Gbps
Layer	Layer 2
Form Factor	Rack-mountable
Power Supply	Internal
MAC Address Table Size	8000 entries
Switch Type	Managed
Power over Ethernet (PoE)	No
Stackable	No
Jumbo Frame Support	9216 bytes
VLAN Support	Yes
Quality of Service (QoS)	4 hardware queues
Ports	24
