Configuring Discovery
Configuring CDP
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 80
7
Displaying CDP Local Information
The
CDP Local Information
page displays information that is advertised by the
CDP protocol about the local device.
To view the CDP local information:
STEP 1 Click Administration > Discovery - CDP > CDP Local Information. The
CDP
Local Information
page opens.
STEP 2 Select a local port, and the following fields are displayed:
• Interface—Number of the local port.
• CDP State—Displays whether CDP is enabled or not.
• Device ID Type—Type of the device ID advertised in the device ID TLV.
• Device ID—Device ID advertised in the device ID TLV.
• Address(s)—IP addresses (advertised in the device address TLV).
• Port ID—Identifier of port advertised in the port TLV.
• Capabilities—Capabilities advertised in the port TLV)
• Version—Information about the software release on which the device is
running.
• Platform—Identifier of platform advertised in the platform TLV.
• Native VLAN—The native VLAN identifier advertised in the native VLAN TLV.
• Duplex—Whether port is half or full duplex advertised in the full/half duplex
TLV.
• Appliance ID—Type of device attached to port advertised in the appliance
TLV.
• Appliance VLAN ID—VLAN on the device used by the appliance, for
instance if the appliance is an IP phone, this is the voice VLAN.
• Extended Trust—Enabled indicates that the port is trusted, meaning that the
host/server from which the packet is received is trusted to mark the packets
itself. In this case, packets received on such a port are not re-marked.
Disabled indicates that the port is not trusted in which case, the following
field is relevant.
