VLAN Management
Voice VLAN
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 178
12
To view Auto Voice VLAN parameters:
STEP 1 Click VLAN Management > Voice VLAN > Auto Voice VLAN. The
Auto Voice
VLAN
page
opens.
The operation status block on this page shows the information about the current
voice VLAN and its source:
• Auto Voice VLAN Status—Displays whether Auto Voice VLAN is enabled.
• Voice VLAN ID—The identifier of the current voice VLAN
• Source Type—Displays the type of source where the voice VLAN is
discovered by the root switch.
• CoS/802.1p—Displays CoS/802.1p values that will be used by the LLDP-
MED as a voice network policy.
• DSCP—Displays DSCP values that will be used by the LLDP-MED as a voice
network policy.
• Root Switch MAC Address—The MAC address of the Auto Voice VLAN root
device that discovers or is configured with the voice VLAN from which the
voice VLAN is learned.
• Switch MAC Address—Base MAC address of the switch. If the device's
Switch MAC address is the Root Switch MAC Address, the device is the
Auto Voice VLAN root device.
• Voice VLAN ID Change Time—Last time that voice VLAN was updated.
STEP 2 Click Restart Auto Voice VLAN to reset the voice VLAN to the default voice VLAN
and restart Auto Voice VLAN discovery on all the Auto-Voice-VLAN-enabled
switches in the LAN.
The Voice VLAN Local Table contains local voice VLAN configuration as well as
any voice VLAN configuration advertised by directly connected neighbor devices:
For each port the Best Local Source is indicated, as follows:
• Yes—The switch uses this voice VLAN to synchronize with other Auto Voice
VLAN-enabled switches. This voice VLAN will be the voice VLAN for the
network unless a voice VLAN from a higher priority source is discovered.
Only one local source is the best local source.
• No—This is not the best local source.
