Configuring the Spanning Tree Protocol
Defining Spanning Tree Interface Settings
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 186
13
• Path Cost—Set the port contribution to the root path cost or use the default
cost generated by the system.
• Priority—Set the priority value of the port. The priority value influences the
port choice when a bridge has two ports connected in a loop. The priority is
a value from 0 to 240, set in increments of 16.
• Port State—Displays the current STP state of a port.
-
Disabled
—STP is currently disabled on the port. The port forwards
traffic while learning MAC addresses.
-
Blocking
—The port is currently blocked, and cannot forward traffic (with
the exception of BPDU data) or learn MAC addresses.
-
Listening
—The port is in Listening mode. The port cannot forward traffic,
and cannot learn MAC addresses.
-
Learning
—The port is in Learning mode. The port cannot forward traffic,
but it can learn new MAC addresses.
-
Forwarding
—The port is in Forwarding mode. The port can forward
traffic and learn new MAC addresses.
• Designated Bridge ID—Displays the bridge priority and the MAC address
of the designated bridge.
• Designated Port ID—Displays the priority and interface of the selected
port.
• Designated Cost—Displays the cost of the port participating in the STP
topology. Ports with a lower cost are less likely to be blocked if STP detects
loops.
• Forward Transitions—Displays the number of times the port has changed
from the Blocking state to Forwarding state.
• Speed—Displays the speed of the port.
• LAG—Displays the LAG to which the port belongs. If a port is a member of
a LAG, the LAG settings override the port settings.
STEP 4 Click Apply. The interface settings are modified, and the Running Configuration file
is updated.
