Configuring Multicast Forwarding
Querying IGMP/MLD IP Multicast Group
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 207
15
• Last Member Query Counter—Enter the Last Member Query Count to be
used if the switch cannot derive the value from the messages sent by the
elected querier.
• Operational Last Member Query Counter—Displays the operational value
of the Last Member Query Counter.
• Last Member Query Interval—Enter the Maximum Response Delay to be
used if the switch cannot read Max Response Time value from Group-
Specific queries sent by the elected querier.
• Operational Last Member Query Interval—The Last Member Query
Interval sent by the elected querier.
• Immediate Leave—When enabled, reduces the time it takes to block
unnecessary MLD traffic sent to a switch port.
STEP 5 Click Apply. The Running Configuration file is updated.
Querying IGMP/MLD IP Multicast Group
The
IGMP/MLD IP Multicast Group
page displays the IPv4 and IPv6 group address
learned from IGMP/MLD messages.
There might be a difference between information on this page and, for example,
information displayed in the
MAC Group Address
page
.
Assuming that the system
is in MAC-based groups and a port that requested to join the following Multicast
groups 224.1.1.1 and 225.1.1.1, both are mapped to the same MAC Multicast
address 01:00:5e:01:01:01. In this case, there is a single entry in the
MAC Multicast
page, but two entries on this page.
To query for a IP Multicast group:
STEP 1 Click Multicast > IGMP/MLD IP Multicast Group. The IGMP/MLD IP Multicast
Group page opens.
STEP 2 Set the type of snooping group for which to search: IGMP or MLD.
STEP 3 Enter some or all of following query filter criteria:
• Group Address equals to—Defines the Multicast group MAC address or IP
address to query.
