Configuring Discovery
Configuring LLDP
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 72
7
802.1 VLAN and Protocol
• PVID—Advertised port VLAN ID.
PPVID
• VID—Protocol VLAN ID.
• Supported—Supported Port and Protocol VLAN IDs.
• Enabled—Enabled Port and Protocol VLAN IDs.
VLAN IDs
• VID—Port and Protocol VLAN ID.
• VLAN Names—Advertised VLAN names.
Protocol IDs
• Protocol ID Table—Advertised protocol IDs.
Location Information
Enter the following data structures in hexadecimal as described in section
10.2.4 of the ANSI-TIA-1057 standard:
• Civic—Civic or street address.
• Coordinates—Location map coordinates—latitude, longitude, and altitude.
• ECS ELIN—Device’s Emergency Call Service (ECS) Emergency Location
Identification Number (ELIN).
• Unknown—Unknown location information.
Network Policies
• Application Type—Network policy application type, for example, Voice.
• VLAN ID—VLAN ID for which the network policy is defined.
• VLAN Type—VLAN type, Tagged or Untagged, for which the network policy
is defined.
• User Priority—Network policy user priority.
• DSCP—Network policy DSCP.

Cisco SF200-24 Specifications

General

Model	SF200-24
Switching Capacity	8.8 Gbps
Layer	Layer 2
Form Factor	Rack-mountable
Power Supply	Internal
MAC Address Table Size	8000 entries
Switch Type	Managed
Power over Ethernet (PoE)	No
Stackable	No
Jumbo Frame Support	9216 bytes
VLAN Support	Yes
Quality of Service (QoS)	4 hardware queues
Ports	24
