Cisco SGE2000 User Manual

110
Chapter 6: Configuring VLANs
Defining Interface Settings
SGE2000/SGE2000P Gigabit Ethernet Switch Reference Guide
Chapter
6
• PVID — Assigns a VLAN ID to untagged packets. The possible values are 2 to 4094. VLAN 4095
is defined as per standard and industry practice as the discard VLAN. Packets classified to the
Discard VLAN are dropped.
• Frame Type — Packet type accepted on the port. Possible values are:
– Admit Tag Only — Indicates that only tagged packets are accepted on the port.
– Admit All — Indicates that both tagged and untagged packets are accepted on the port.
• Ingress Filtering — Enables or disables Ingress filtering on the port. Ingress filtering discards
packets which do not include an ingress port.
3. Define the relevant fields.
4. Click Apply. The VLAN Interface settings are modified, and the device is updated.

Cisco SGE2000 Specifications

General

Jumbo Frame Support	9KB
VLANs	Up to 256
Management	Web-based, SNMP, CLI
Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1Q, 802.1p, 802.1w
Dimensions	440 x 44 x 257 mm
Power Supply	100 to 240V AC, 50-60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Weight	3.2 kg
