126
Chapter 7: Configuring IP Information
Configuring Layer 2
SGE2000/SGE2000P Gigabit Ethernet Switch Reference Guide
Chapter
7
corresponding IP address. The ARP table can be filled in statically by the user. When a static ARP entry
is defined, a permanent entry is put in the table, which the system uses to translate IP addresses to MAC
addresses. To define ARP:
1. Click System > System Management > IP Addressing > ARP. The ARP Page opens:
ARP Page
The ARP Page contains the following fields.
• ARP Entry Age Out — Defines the amount of time (seconds) that pass between ARP requests
about an ARP table entry. After this period, the entry is deleted from the table. The range is 1 -
40000000, where zero indicates that entries are never cleared from the cache. The default value is
60,000 seconds.
• Clear ARP Table Entries— Indicates the type of ARP entries that are cleared on all devices. The
possible values are:
– None — ARP entries are not cleared.
– All — All ARP entries are cleared.
– Dynamic — Only dynamic ARP entries are cleared.
– Static — Only static ARP entries are cleared.
• Interface — Indicates the interface connected to the device.
• IP Address — Indicates the station IP address, which is associated with the MAC address filled in
below.
