194
Chapter 11: Configuring SNMP
Defining Trap Management
SGE2000/SGE2000P Gigabit Ethernet Switch Reference Guide
Chapter
11
SNMP Notification Receiver Page
The SNMP Notification Receiver Page contains the following fields:
• Recipients IP — Indicates the IP address to whom the traps are sent.
• Notification Type — Defines the notification sent. The possible field values are:
– Trap — Indicates traps are sent.
– Inform — Indicates informs are sent.
The SNMPv1,2 Notification Recipient area contains the following fields:
• SNMPv1,2 — Enables SNMPv1,2 as the Notification Recipient. Either SNMPv1,2 or SNMPv3 can
be enabled at any one time, but not both at the same time. If SNMPv1,2 is enabled, the Community
String and Notification Version fields are enabled for configuration:
• Community String — (SNMP v1, 2) Identifies the community string of the trap manager.
• Notification Version — (SNMP v1, 2) Determines the trap type. The possible field values are:
– SNMP V1 — Indicates SNMP Version 1 traps are sent.
– SNMP V2 — Indicates SNMP Version 2 traps are sent.
The SNMPv3 Notification Recipient area contains the following fields:
• SNMPv3 — Enables SNMPv3 as the Notification Recipient. Either SNMPv1,2 or SNMPv3 can be
enabled at any one time, but not both at the same time. If SNMPv3is enabled, the User Name and
Security Level fields are enabled for configuration:

Cisco SGE2000 Specifications

General

Jumbo Frame Support	9KB
VLANs	Up to 256
Management	Web-based, SNMP, CLI
Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1Q, 802.1p, 802.1w
Dimensions	440 x 44 x 257 mm
Power Supply	100 to 240V AC, 50-60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Weight	3.2 kg
