Chapter 16: Viewing Statistics
Viewing Ethernet Statistics
SGE2000/SGE2000P Gigabit Ethernet Switch Reference Guide
Chapter
16
• Respond Frames Receive — Indicates the number of EAP Resp/Id frames that have been received
on the port.
• Request ID Frames Transmit — Indicates the number of EAP Req/Id frames transmitted via the
port.
• Request Frames Transmit — Indicates the number of EAP Request frames transmitted via the port.
• Invalid Frames Receive — Indicates the number of unrecognized EAPOL frames that have been
received by on this port.
• Length Error Frames Receive — Indicates the number of EAPOL frames with an invalid Packet
Body Length received on this port.
• Last Frame Version — Indicates the protocol version number attached to the most recently
received EAPOL frame.
• Last Frame Source — Indicates the source MAC address attached to the most recently received
EAPOL frame.

Cisco SGE2000 Specifications

General

Jumbo Frame Support	9KB
VLANs	Up to 256
Management	Web-based, SNMP, CLI
Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1Q, 802.1p, 802.1w
Dimensions	440 x 44 x 257 mm
Power Supply	100 to 240V AC, 50-60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Weight	3.2 kg
