266
Chapter 16: Viewing Statistics
Managing RMON Statistics
SGE2000/SGE2000P Gigabit Ethernet Switch Reference Guide
Chapter
16
• Sample Type — Defines the sampling method for the selected variable and comparing the value
against the thresholds. The possible field values are:
– Delta — Subtracts the last sampled value from the current value. The difference in the
values is compared to the threshold.
– Absolute — Compares the values directly with the thresholds at the end of the sampling
interval.
• Rising Threshold — Displays the rising counter value that triggers the rising threshold alarm. The
rising threshold is presented on top of the graph bars. Each monitored variable is designated a color.
• Rising Event — Selects an event which is defined in the Events table that triggers the rising
threshold alarm. The Events Table is displayed in the RMON Events page.
• Falling Threshold — Displays the falling counter value that triggers the falling threshold alarm.
The falling threshold is graphically presented on top of the graph bars. Each monitored variable is
designated a color.
• Falling Event — Selects an event which is defined in the Events table that triggers the falling
threshold alarm. The Events Table is displayed in the RMON Events page.
• Startup Alarm — Displays the trigger that activates the alarm generation. Rising is defined by
crossing the threshold from a low-value threshold to a higher-value threshold.
• Interval — Defines the alarm interval time in seconds.
• Owner — Displays the device or user that defined the alarm.
3. Define the relevant fields.
4. Click Apply. The RMON alarm is added, and the device is updated.
Modify RMON Alarm Settings
1. Click Statistics > RMON > Alarms. The RMON Alarms Page opens:
2. Click the Edit Button. The Edit RMON Alarms Page opens:
