Cisco UCS 5108 Installation Guide

SpecificationItem
Accepts Panduit LCD4-14AF-L or equivalent
barrel-type lug terminals with 90-degree angle, two-
hole tongue, which accommodates 1/0 AWG size
copper wire. The connector tongue width is 0.82 in,
the stud hole spacing is 5/8 in, and the hole size is 1/4
in.
DC input terminal block
8 ms at 50% load
4 ms at 100% load
Maximum holdup time
Table 22: HVDC-Input Platinum Power Supply (UCSB-PSU-2500HVDC) Specifications
SpecificationItem
200 to 380 VDC nominal (Range: 180 to 400 VDC)DC-input voltage
15.5 Amps @ 200 VDCMaximum DC-input current
2500 WMaximum output power
35 AMaximum inrush current
Climate Savers PlatinumEfficiency rating
10% 20% 50% 100%
93.5% 94.9% 95% 93%
Efficiency (80 Plus Platinum Certified)
12 VDCPower supply output voltage
12 ms 2500 WMaximum holdup time
IEC320 C20Input connector
Table 23: AC-input Dual Voltage Platinum Power Supply (UCSB-PSU-2500ACDV) Specifications
SpecificationDescription
200 to 240 VAC nominal (Range: 180 to 264 VAC)
100 to 120 VAC nominal (Range: 90 to 127 VAC)
supported only with the UCS 6324 Fabric Interconnect
AC-input voltage
50 and 60 Hz nominal (Range: 47 to 63 Hz)AC-input frequency
< 15 Amps @ 200 VACAC-input current
Cisco UCS 5108 Server Chassis Installation Guide
90
Technical Specifications
Specifications for the Cisco UCS 5108 Blade Server Chassis Power Supply Units

Cisco UCS 5108 Specifications

General

Number of Blade Slots	8
I/O Module Bays	2
Supported Blade Servers	Cisco UCS B-Series Blade Servers
Power Supply Options	Up to four hot-swappable power supplies (AC or DC)
Cooling	Redundant hot-swappable fans
Management	Cisco UCS Manager
Blade Slots	8
Fabric Interconnects	Cisco UCS 6100 or 6200 Series
Power Supplies	Up to 4 hot-pluggable power supplies
Form Factor	6RU rack-mountable
