Cisco UCS 5108 Installation Guide

DateTimeVerified ByPlanning ActivityTask No.
Environmental evaluation:
•
Ambient temperature
•
Humidity
•
Altitude
•
Atmospheric contamination
•
Air flow
2
Power evaluation:
•
Input power type
•
Power receptacles
6
•
Receptacle proximity to the
equipment
•
Dedicated circuit for power supply
•
Dedicated (separate) circuits for
redundant power supplies
•
UPS
7
for power failures
3
Grounding evaluation:
•
Circuit breaker size
•
CO ground (AC- powered systems)
4
Cable and interface equipment evaluation:
•
Cable type
•
Connector type
•
Cable distance limitations
•
Interface equipment (transceivers)
5
EMI
8
evaluation:
•
Distance limitations for signaling
•
Site wiring
•
RFI
9
levels
6
6
Verify that the power supply installed in the chassis has a dedicated AC source circuit.
7
UPS: uninterruptable power supply.
Cisco UCS 5108 Server Chassis Installation Guide
98
Site Planning and Maintenance Records
Site Preparation Checklist

Cisco UCS 5108 Specifications

General

Number of Blade Slots	8
I/O Module Bays	2
Supported Blade Servers	Cisco UCS B-Series Blade Servers
Power Supply Options	Up to four hot-swappable power supplies (AC or DC)
Cooling	Redundant hot-swappable fans
Management	Cisco UCS Manager
Blade Slots	8
Fabric Interconnects	Cisco UCS 6100 or 6200 Series
Power Supplies	Up to 4 hot-pluggable power supplies
Form Factor	6RU rack-mountable
