Table 6: Blade Server LEDs
DescriptionColorLED
Power off.OffPower
Normal operation.Green
Standby.Amber
None of the network links are up.OffLink
At least one network link is up.Green
Power off.OffHealth
Normal operation.Green
Minor error.Amber
Critical error.Blinking
Amber
Inactive.OffActivity
(Disk Drive)
Outstanding I/O to disk drive.Green
No fault.OffHealth
(Disk Drive)
Some fault.Amber
Cisco UCS 5108 Server Chassis Installation Guide
39
Overview
Interpreting LEDs
