UNITY INSTALLATION GUIDE
122
Dialogic D/41ESC
Continued
voice board
Hardware settings
Do the following procedures as you install voice boards.
To set the SW1 switch
For each Dialogic ISA voice board that has a rotary switch,
set the rotary switch to a unique value starting with 0 and
continuing in sequence.
For example, set the rotary switch on the first three ISA
voice boards in the Unity server as shown below. This is also
the order in which you install the boards in the server.
To set switch block SW2
Set SW2 switches to “Off” on all boards.
First ISA board
Second ISA board
Third ISA board
0
1
2
