Cisco Unity - Dialogic D;41 E PCI Voice Board

APPPENDIX A:
Voice and fax boards
119
Dialogic
D/41E PCI
voice board
Continued
Jumpers
JP2–JP5
Jumpers
JP6–JP7
Switch
SW1
Switch
SW2
Voice board backplate
Line 1
Line 2
Connection pinouts
The D/41E PCI uses
RJ-11 connectors.
Line 3
Line 4
Side view
Pin 4: Unused
Pin 3: Ring
Pin 2: Tip
Pin 1: Unused
