Cisco Unity - Dialogic Gammalink Cpi;200 Fax Board

UNITY INSTALLATION GUIDE
144
Dialogic
GammaLink
CPi/200
fax board
LED status indicators
Fax board backplate
Pin 3: First fax line tip
Pin 2: First fax line ring
Connection pinouts
The CPi/200 uses an
RJ-14 connector.
Lines 1 & 2
Pin 1: Second fax line tip
Pin 4: Second fax line ring
Switch block SW1
Side view
