Citrix ADC MPX Series User Manual

Citrix ADC MPX
Change the administrative password by using the GUI
1. Log on to the appliance by using the administrative credentials.
2. On the Configuration tab, in the navigation pane, expand System, and then click Users.
3. In the Users pane, click the default user account (nsroot), and then click Change Password.
4. In the Change Password dialog box, in Password and Confirm Password, type the password of
your choice.
5. Click OK.
Change the administrative password by using the CLI
At the command prompt, type:
set system user <userName> -password
Example:
set system user nsroot -password
Enter password: *****
Confirm password: *****
Done
Lights out management port of the Citrix ADC MPX appliance
November 18, 2019
Some Citrix ADC appliances have an Intelligent Platform Management Interface (IPMI), also known as
the lights out management (LOM) port, on the front panel of the appliance. You can use the LOM port
to remotely monitor and manage the appliance, independently of the Citrix ADC soware.
Connect the LOM port to a dedicated channel that is separate from the data channel, to maintain
connectivity to the appliance even if the data network is down. You eliminate the data cable and data
network as a single point of failure.
You can access the LOM port through a browser and use the GUI (GUI) for most tasks. All tasks can be
performed through the Citrix ADC shell.
You can use either the GUI or a shell for the following tasks:
• Configuring the network settings
• Health monitoring
• Power control operations
• Factory reset
© 1999-2019 Citrix Systems, Inc. All rights reserved. 137

Citrix ADC MPX Series Specifications

General

Type	Application Delivery Controller
Memory	Up to 256 GB
Power Supply	Redundant
Product Series	MPX
Ports	10/25/40/100 Gbps Ethernet
Operating System	Citrix ADC
Management	Citrix ADM
Form Factor	Rack-mountable
