Citrix ADC MPX
– Ifthe OS is functional, press the switch for less than two seconds to power down the system
with a graceful shutdown.
– If the OS is not responsive, press the power switch for more than 4 seconds to force the
power o.
• Two hot-swappable 100–240 VAC, 1200 W power supply modules. Max power consumption is
764 W. Typical power consumption is 628 W. Each power supply has an LED indicating its status:
LED Color LED Indicates
OFF No power to any power supply on the
appliance.
Flashing RED No power to this power supply.
Flashing GREEN Power supply is in standby mode.
GREEN Power supply is functional.
RED Power supply failure.
Flashing RED and GREEN Warning; (OVP/UVP/OCP/OTP/Fan); OVP = Over
Voltage Protection; UVP = Under Voltage
Protection; OCP = Over Current Protection;
OTP = Over Temperature Protection
• Disable alarm button. Press this button to silence the power alarm when one of two power
supplies loses input power or when a power supply is malfunctioning.
• Non-Maskable Interrupt (NMI) Button, used at the request of Technical Support to initiate a core
dump. To press this red button, which is recessed to prevent unintentional activation, use a pen,
pencil, or other pointed object. The NMI Button is also available remotely over the network in
the LOM GUI, in the Remote Control menu. For more information about the lights out manage-
ment port of the appliance, see Lights out management port of the Citrix ADC MPX appliance.
Citrix ADC MPX 26xxx-100G
October 25, 2019
The Citrix ADC MPX 26000-100G and MPX 26000T-100G appliances are 2U appliance. These appliances
have two 14-core processorsand 256 GB of memory. The appliances provide a total of 8 network ports:
Four cards with dual 100G SFP+ Ethernet Ports.
For information about the soware releases supported on the Citrix ADC hardware platforms, see Cit-
rix ADC MPX hardware soware compatibility matrix.
© 1999-2019 Citrix Systems, Inc. All rights reserved. 79
