Citrix ADC MPX Series User Manual

Citrix ADC MPX
• One 256 GB removable solid-state drive, which is used to store the Citrix ADC soware and the
user data.
Note: Earlier MPX 8005/8015/8200/8400/8600/8800 appliances had three additional SSD slots
for future use. Current Citrix ADC MPX 8005/8015/8200/8400/8600/8800 appliances do not have
any additional SSD slots for future use.
• Power switch, which turns o power to the appliance, just as if you were to unplug the power
supply. Press the switch for five seconds to turn o the power.
• USB port (reserved for a future release).
• Non-maskable interrupt (NMI) button, which is used at the request of Technical Support to pro-
duce a Citrix ADC core dump. You must use a pen, pencil, or other pointed object to press this
red button, which is recessed to prevent unintentional activation.
• Disable alarm button, which is nonfunctional. This button is functional only if you install a sec-
ond power supply.
Press this button to stop the power alarm from sounding when you have plugged the appliance
into only one power outlet, or when one power supply is malfunctioning and you want to con-
tinue operating the appliance until it is repaired.
• Single power supply, rated at 450 watts, 110-220 volts. Maximum power consumption is 250
watts and typical power consumption is 185 watts.
Note: The MPX 8005/8015/8200/8400/8600/8800 appliance supports dual power supplies, but ships
with one power supply. Contact your Citrix sales representative to order a second power supply.
For information about installing the rails, rack mounting the hardware, and connecting the cables,
see Hardware installation.
For information about performing initial configuration of your appliance, see Citrix ADC initial config-
uration.
Citrix ADC MPX 89xx
April 19, 2019
The the Citrix ADC MPX 89xx appliance is a 1U appliance. This platform has a single 8-core processor
and 32 GB of memory. The appliance provides a total of 10 network ports:
• Six 10/100/1000Base-T RJ45 copper Ethernet Ports.
• Four 10G/1G SFP+ Ethernet Ports.
© 1999-2019 Citrix Systems, Inc. All rights reserved. 36

Citrix ADC MPX Series Specifications

General

Type	Application Delivery Controller
Memory	Up to 256 GB
Power Supply	Redundant
Product Series	MPX
Ports	10/25/40/100 Gbps Ethernet
Operating System	Citrix ADC
Management	Citrix ADM
Form Factor	Rack-mountable
