Citrix ADC MPX
Obtain the MAC address, serial number, and host properties of the
appliance
February 11, 2019
A Media Access Control address (MAC address) is a unique identifier assigned to network interfaces for
communication on the physical network segment. The serial number is on the back panel of the ap-
pliance. If you do not have easy access to the back panel, you can get the appliance’s serial number by
logging on to the LOM port. You can also retrieve the parameter settings assigned to the IP addresses
configured on the appliance, such as the state of ARP, ICMP, telnet, secure shell access, and dynamic
routing.
To obtain the MAC address, serial number, and host properties of the appliance by
using the LOM GUI
1. In the Menu bar, click Remote Control.
2. Under Options, click Console Redirection.
3. Click Launch Console, and then click Yes.
4. Type the administrator credentials.
5. Type show interface <management_interface_id> to display the MAC address.
6. Type show hardware to display the serial number of the appliance.
7. Type sh nsip to display the host properties of the appliance.
Obtain the MAC address and host properties of the BMC by using the appliance shell
At the shell prompt, type:
ipmitool lan print
Example:
1 Set in Progress : Set Complete
2 Auth Type Support : MD2 MD5 OEM
3 Auth Type Enable : Callback : MD2 MD5 OEM
4 : User : MD2 MD5 OEM
5 : Operator : MD2 MD5 OEM
6 : Admin : MD2 MD5 OEM
7 : OEM :
8 IP Address Source : Static Address
9 IP Address : 192.168.1.3
10 Subnet Mask : 255.255.255.0
© 1999-2019 Citrix Systems, Inc. All rights reserved. 149

Citrix ADC MPX Series Specifications

General

Type	Application Delivery Controller
Memory	Up to 256 GB
Power Supply	Redundant
Product Series	MPX
Ports	10/25/40/100 Gbps Ethernet
Operating System	Citrix ADC
Management	Citrix ADM
Form Factor	Rack-mountable
