Citrix ADC MPX Series User Manual

Citrix ADC MPX
Health attributes for MPX 22040 platform
The following table lists the health attributes for MPX 22040/22060/22080/22100/22120.
Health
attribute
Unit Lower
Non-
Recoverable
Lower
Critical
Lower
Non-
Critical
Upper
Non-
Critical
Upper
Critical
Upper
Non-
Recoverable
CPU1
Temp
degrees C 0.000 0.000 0.000 90.000 93.000 95.000
CPU2
Temp
degrees C 0.000 0.000 0.000 90.000 93.000 95.000
System
Temp
degrees C -9.000 -7.000 -5.000 80.000 85.000 90.000
Peripheral
Temp
degrees C -9.000 -7.000 -5.000 80.000 85.000 90.000
PCH
Temp
degrees C -11.000 -8.000 -5.000 90.000 95.000 100.000
FPC_Temp
1
degrees C - NA - - NA - - NA - 66.000 70.000 75.000
FPC_Temp
2
degrees C - NA - - NA - - NA - 72.000 76.000 82.000
FPC_Temp
3
degrees C - NA - - NA - - NA - 72.000 76.000 82.000
HDDBP_Temp
1
degrees C - NA - - NA - - NA - 72.000 76.000 82.000
HDDBP_Temp
2
degrees C - NA - - NA - - NA - 72.000 76.000 82.000
FAN 1 RPM - NA - 1980.000 - NA - - NA - - NA - - NA -
FAN 2 RPM - NA - 1980.000 - NA - - NA - - NA - - NA -
FAN 3 RPM - NA - 1980.000 - NA - - NA - - NA - - NA -
FAN 4 RPM - NA - 1980.000 - NA - - NA - - NA - - NA -
FAN 5 RPM - NA - 1980.000 - NA - - NA - - NA - - NA -
FAN 6 RPM - NA - 1980.000 - NA - - NA - - NA - - NA -
FAN 7 RPM - NA - 1980.000 - NA - - NA - - NA - - NA -
© 1999-2019 Citrix Systems, Inc. All rights reserved. 159

Citrix ADC MPX Series Specifications

General

Type	Application Delivery Controller
Memory	Up to 256 GB
Power Supply	Redundant
Product Series	MPX
Ports	10/25/40/100 Gbps Ethernet
Operating System	Citrix ADC
Management	Citrix ADM
Form Factor	Rack-mountable
