Citrix ADC MPX Series User Manual

Citrix ADC MPX
PS_4
Temp
degrees C - NA - - NA - - NA - - NA - - NA - - NA -
FPC
Status
discrete - NA - - NA - - NA - - NA - - NA - - NA -
VTT Volts 0.816 0.864 0.912 1.344 1.392 1.440
CPU1
Vcore
Volts 0.480 0.512 0.544 1.488 1.520 1.552
CPU2
Vcore
Volts 0.480 0.512 0.544 1.488 1.520 1.552
VDIMM
AB
Volts 1.104 1.152 1.200 1.648 1.696 1.744
VDIMM
CD
Volts 1.104 1.152 1.200 1.648 1.696 1.744
VDIMM
EF
Volts 1.104 1.152 1.200 1.648 1.696 1.744
VDIMM
GH
Volts 1.104 1.152 1.200 1.648 1.696 1.744
+1.5 V Volts 1.248 1.296 1.344 1.648 1.696 1.744
3.3 V Volts 2.640 2.784 2.928 3.648 3.792 3.936
+3.3VSB Volts 2.640 2.784 2.928 3.648 3.792 3.936
5 V Volts 4.096 4.288 4.480 5.504 5.696 6.912
12 V Volts 10.176 10.494 10.812 13.250 13.568 13.886
VBAT Volts 2.400 2.544 2.688 3.312 3.456 3.600
Health attributes for MPX 5900 platform
The following table lists the health attributes for MPX 5900 platform.
Health Attribute Recommended Range
CPU 0 core (Volts) 1.77–1.81
Main 3.3 V Supply (Volts) 3.25–3.32
Standby 3.3 V Supply (Volts) 3.27–3.32
© 1999-2019 Citrix Systems, Inc. All rights reserved. 163

Citrix ADC MPX Series Specifications

General

Type	Application Delivery Controller
Memory	Up to 256 GB
Power Supply	Redundant
Product Series	MPX
Ports	10/25/40/100 Gbps Ethernet
Operating System	Citrix ADC
Management	Citrix ADM
Form Factor	Rack-mountable
