Citrix ADC MPX
The following figure shows the front panel of the T1200 appliance.
Figure 1. Citrix ADC T1200 front panel
The T1200 appliance has the following ports:
• 24 10GBASE-X SFP+ data plane ports
• 12 1000BASE-X SFP data plane ports
• Two 10/100/1000BASE-T, RJ45 management ports
• One 10/100BASE-T, RJ-45 LOM port
The following figure shows the back panel of the T1200 appliance.
Figure 2. Citrix ADC T1200 back panel
The following components are visible on the back panel of the T1200 appliance:
• System status LED, which indicates the status of the appliance, as described in LCD Display and
LED Status Indicators.
• Four power supplies, each rated at 750 watts, 100-240 volts. A minimum of two power supplies
are required for proper operation. The extra power supplies act as backup. Each power supply
has an LED that indicates the status of the power supply, as described in LCD Display and LED
Status Indicators.
© 1999-2019 Citrix Systems, Inc. All rights reserved. 87
