Citrix ADC MPX Series User Manual

Citrix ADC MPX
Power Supply 450 W AC 450 W DC 1000 W AC 1000 W DC 1200 W AC
LED behavior
when
YM-2451CAR YM-2451DBR YM-
2102NA01R
YM-
2102JA01R
YM-
2122CA01R
No Power to
any power
supply
O O O O O
No power to
this power
supply
Flashing RED Flashing RED Flashing RED Flashing RED Flashing RED
Power supply
is in standby
mode
Flashing
GREEN
Flashing
BLUE
Flashing
GREEN
Flashing
GREEN
Flashing
GREEN
Power supply
is functional
GREEN BLUE GREEN GREEN GREEN
Power supply
failure
RED RED RED RED RED
Warning
(OVP/U-
VP/OCP/OTP/-
Fan)
- - - Flashing
RED/GREEN
-
Note
The followinglegacy platformsuse the 300W 3Y power supply: 5850/5750/5650/5550/5500/5600.
Acbel power supply
The Acbel power supply is used on the following platforms:
• 450 W AC
– MPX 59xx
– MPX 89xx
• 450 W DC
– MPX 59xx
– MPX 89xx
Acbel 450 W power supply LED behavior
© 1999-2019 Citrix Systems, Inc. All rights reserved. 9

Citrix ADC MPX Series Specifications

General

Type	Application Delivery Controller
Memory	Up to 256 GB
Power Supply	Redundant
Product Series	MPX
Ports	10/25/40/100 Gbps Ethernet
Operating System	Citrix ADC
Management	Citrix ADM
Form Factor	Rack-mountable
