WS2H and WS3 Manual Page 19
SYSTEM SETUP 3B - Select isolation type
• Piston: Factory motorized isolation drive has an internal piston & seals similar to the main
piston
• Poppet: Factory motorized isolation drive uses a at disc “face” seal
• Relay: Isolation will be done through the optional board relays & does not initialize the
BYPASS motorized drive circuit
SYSTEM SETUP SCREENS (CONTINUED)
SYSTEM SETUP 3B
Non-Default Settings
SYSTEM SETUP 4 - Day override control
• 28 day time clock: Used to regenerate units based on a set number of days between
regenerations
• 7 Day Time Clock: Used to control regeneration based on speci c days
• OFF: Days have no control on regenerations, and will not be a selection if volumetric
capacity is set to OFF
SYSTEM SETUP 4
Non-Default Settings
SYSTEM SETUP 5
SYSTEM SETUP 5 - Regeneration control
Delayed 1 – 4
• Delays regeneration of units upon reaching 0 gallons capacity
• Allows setting of up to 4 regeneration times per day
• Systems with delayed regen will remove a unit from service based upon 0 capacity and
regenerate at the scheduled regen time.
- Only one unit will regen / scheduled time
• Day driven regens will regen at the DEL-1 time slot
• Depleted units will regen at the next available delayed time slot
On 0
-Immediate regeneration of units upon reaching 0 capacity
-Series regeneration systems set to On0 will sequentially regenerate all units at the
delayed time based on day override
Non-Default Settings
