Clear-Com LQ series User Manual

10
399G116 Rev D
Figure 1-3 Partyline to beltpack
Figure 1-4 Partyline to matrix (2-wire to 4-wire)
Figure 1-5 Panel data over 4-wire connection. Replaces VoICE 2.0 product.
Note: Panel data is passed between a pair of LQ devices, providing a 4-wire direct
connection between two ports.
LAN, WAN,
Internet
PoE or local
power
LAN, WAN,
Internet
LQ 2W
LQ 4W
