12 Using LQ™ to interconnect equipment
When connecting LQ units to other Clear-Com products and third party intercom
systems please use the following guidelines:
Device type Which LQ
unit?
Port Function Supports
call
signaling?
Panel
data?
HelixNet HLI-4W2 LQ-4W2
LQ-R4W8
LQ-R2W4-4W4
To panel Yes No
HelixNet HLI-2W2
(Note: this
connection is not
preferred for
optimum audio
quality)
LQ-2W2
LQ-R2W4
LQ-R2W4-4W4
N/A Yes No
MVX-A16/Eclipse
Pico
LQ-4W2
LQ-R4W8
LQ-R2W4-4W4
To matrix
(Identified as a
CCI-22 see 12.3
below.)
Yes Yes
Other matrices
(3
rd
party)
LQ-4W2
LQ-R4W8
LQ-R2W4-4W4
To panel No No
Encore MS-702/4 LQ-2W2
LQ-R2W4
LQ-R2W4-4W4
N/A Yes No
Encore RS
Beltpack 1/2/3
LQ-2W2
LQ-R2W4
LQ-R2W4-4W4
N/A Yes No
