1.2 Basic example applications
Figure 1-1 Partyline to partyline (2-wire connection)
Figure 1-2 Partyline to partyline (2-wire connection). 8 ports,
2 per LQ unit
LAN, WAN,
Internet
LAN, WAN,
Internet
