6 Front panel interface walk-through
From the front panel of the LQ you can:
• Set audio configuration
o input gain
o output gain
• Set VOX configuration
o VOX
o Threshold
o Delay
• Set 2-wire specific settings
o Powering of the line
o Clear-Com/RTS mode
o Auto-nulling
o Termination
• Set 4-wire specific settings
o Port Function: set port function of Ethernet cable ‘to Matrix’ or ‘to
Panel’,
o Vox levels
o Baud rate
• Set device settings
o Brightness of OLED
o Screensaver time-out
o Reboot
o Reset-to-default
• Display only
o Networking: mode, IP, MAC.
