InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
NOTE:
Use low speed for long distance connection only. Set all connected
controllers to the same speed.
12.2.3.13 Setpoint: CAN2emptDetect
Enables the detection of missing other controllers on the CAN2 bus. If the
setpoint is in ENABLED position and there aren't any other controllers
detected on the CAN2 bus (the complete bus, not only within the logical
group) the alarm CAN2Empty is issued.
12.2.3.14 Setpoint: SHxOcol detect
This setpoint is used to enable/disable evaluation of collisions of virtual
shared peripherial modules. A collision means that there is more than one
source (shared outputs module) active on the CAN2 bus.
NOTE:
In certain situations multiple sites with bus tie breakers may need to have
more shared outputs sources as the CAN bus line is in some points
interrupted according to bus tie breakers position. Normally a collision would
be indicated if there were more sources on the bus and this setpoint can be
used to disable the evaluation of collisions in this special case.
12.2.3.15 Setpoint: CANAddrSwitch1
