ComAp IGS-NT Series - Page 135

IGS-NT Installation Guide
135
AVRi+
AVRi-
18VAC
From
generator
OUT1
OUT2
iG-
AVRi
iG
-
AVRi
TRANS
A1
A2
230/400VAC
0VAC
AVRI COM
AVRI OUT
2
1
AVRi trim to minimum
counter clockwise
Volt/PF ctrl:
AVR DCout bias = 50%
VoltRegChar = POSITIVE
Newer Leroy Somer
AVRi+
AVRi-
18VAC
From
generator
OUT1
OUT2
iG-
AVRi
iG
-
AVRi
TRANS
A1
A2
230/400VAC
0VAC
AVRI COM
AVRI OUT
2
1
Regulation signal +/- 0..2,5V
AVRi trim to minimum
counter clockwise
Volt/PF ctrl:
AVR DCout bias = 50%
VoltRegChar = POSITIVE
AVK Newage Cosimat N+
Volt/PF ctrl:
AVR DCout bias = 25%
VoltRegChar = NEGATIVE
Marathon DVR2000E
AVRi
+
AVRi
-
18VAC
From
generator
OUT1
iG-
AVRi
iG
-
AVRi
TRANS
A
B
230/400VAC
0VAC
AVRI COM
AVRI OUT
OUT2
AVRi trim to 1/3 clockwise
Volt/PF ctrl:
AVR DCout bias = 50%
VoltRegChar = POSITIVE
Marathon PM100, 200
AVRi
+
AVRi
-
18VAC
From
generator
OUT1
iG-
AVRi
iG
-
AVRi
TRANS
7
6
230/400VAC
0VAC
AVRI COM
AVRI OUT
OUT2
Volt/PF ctrl:
AVR DCout bias = 50%
VoltRegChar = POSITIVE
MarelliMotori Mark I (M40FA640A/A)
AVRi+
AVRi-
18VAC
From
generator
OUT2
OUT1
iG-
AVRi
iG
-
AVRi
TRANS
230/400VAC
0VAC
AVRI COM
AVRI OUT
6
8
AVRi trim to 20%
Volt/PF ctrl:
AVR DCout bias = 50%
VoltRegChar = POSITIVE
MarelliMotori (M40FA610A)
