InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp June 2013
215
NOTE:
The ratio between the voltage measured at the input terminals and the
displayed voltage is adjusted by the setpoint BusR VT ratio.
13.1.2.4 Value: BusR V L3-N
Group
BusR values
Units
V
Related FW
3.0
Description
BusR voltage in phase L3.
NOTE:
The ratio between the voltage measured at the input terminals and the
displayed voltage is adjusted by the setpoint BusR VT ratio.
13.1.2.5 Value: BusR V
Group
BusR values
Units
V
Related FW
3.0
Description
BusR voltage. Average from all three phases.
NOTE:
The ratio between the voltage measured at the input terminals and the
displayed voltage is adjusted by the setpoint BusR VT ratio.
13.1.2.6 Value: BusR V L1-L2
Group
BusR values
Units
V
Related FW
3.0
Description
BusR voltage phase L1 to L2.
