ComAp IGS-NT Series User Manual

InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
310
OFF
Pressing the button changes the state of log. binary output
User Button X to opened. When the output is opened and
the button is pressed state is not changed.
ON/OFF
Pressing the button changes the state of log. binary output
User Button X to opened or closed depending on previous
state (it is changed to the opposite state).
PULSE ON
Pressing the button issues log. binary output User Button X
to close for one second.
NOTE:
Repeated pressing of button during the closed period (one
second) causes issuing another puls of length of one
second to be generated from the moment of button
pushing.
15.2.1.69 Binary output: User Button 4
Related FW
3.0
Description
This output can be specified for example on buttons on IV-5/8 or in SCADA
diagram in InteliMonitor. Its state depends on function assigned to the related
button.
It is possible to lock UserButton commands in configuration to specific user
level. Buttons 1-8 and 9-16 are locked separately.
ON
Pressing the button changes the state of log. binary output
User Button X to closed. When the output is closed and the
button is pressed state is not changed.
OFF
Pressing the button changes the state of log. binary output
User Button X to opened. When the output is opened and
the button is pressed state is not changed.
ON/OFF
Pressing the button changes the state of log. binary output
User Button X to opened or closed depending on previous
state (it is changed to the opposite state).
PULSE ON
Pressing the button issues log. binary output User Button X
to close for one second.
NOTE:
Repeated pressing of button during the closed period (one
second) causes issuing another puls of length of one
second to be generated from the moment of button
pushing.
