InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
If there is an additional terminal board between a thermocouple and the IS-
AIN8 module and there is a significant temperature difference between this
terminal board and the module, it is necessary to measure the temperature at
this terminal board and use this temperature for the thermocouple
compensation instead of the internal temperature of the module.
This analog input is intended for measuement of this thermocouple
compensation temperature for the IS-AIN8 module with index #1.
NOTE:
Thermocouples without internal compensation "Thermo(nc)..." must be used
for this case.
16.2.1.5 Analog input: Cold temp 2
If there is an additional terminal board between a thermocouple and the IS-
AIN8 module and there is a significant temperature difference between this
terminal board and the module, it is necessary to measure the temperature at
this terminal board and use this temperature for the thermocouple
compensation instead of the internal temperature of the module.
This analog input is intended for measuement of this thermocouple
compensation temperature for the IS-AIN8 module with index #2.
NOTE:
Thermocouples without internal compensation "Thermo(nc)..." must be used
for this case.
16.2.1.6 Analog input: Cold temp 3
If there is an additional terminal board between a thermocouple and the IS-
AIN8 module and there is a significant temperature difference between this
terminal board and the module, it is necessary to measure the temperature at
this terminal board and use this temperature for the thermocouple
compensation instead of the internal temperature of the module.
This analog input is intended for measuement of this thermocouple
compensation temperature for the IS-AIN8 module with index #3.
NOTE:
Thermocouples without internal compensation "Thermo(nc)..." must be used
for this case.
