Events specification
Protection
type
Information on binary
output available (See
list of Binary outputs)
Description
write at least one new parameter.
Overspeed SD YES The protection comes active if the
speed is greater than Overspeed
setpoint.
Underspeed SD YES During starting of the engine when the
RPM reached the value of Starting
RPM setpoint the starter is switched
off and the speed of the engine can
drop under Start RPM again. Then the
Underspeed protection becomes
active. Protection evaluation starts 5
seconds after reaching StartingRPM.
Underspeed WRN YES The protection is active if RPM goes
below the limit adjusted by
Underspeed setpoint.
EmergencyStop SD NO
If the input Emergency stop is opened
shutdown is immediately activated.
PickupFault SD NO Failure of magnetic pick-up sensor for
speed measurement.
Stop fail SD YES Engine stop failed.
WrnServiceTime WRN NO The period for servicing is set by the
NextServTime setpoint. The
protection comes active if the running
hours of the engine reach this value.
ChrgAlternFail WRN YES Failure of alternator for charging the
battery.
SprinklActive WRN NO The protection is active if the output
Sprinkler is closed.
Wrn RA15 fail WRN NO Warning alarm in case of lost
connection to IGL-RA15 module.
Wrn ECU Alarm WRN NO ECU alarm list is not empty
Low BackupBatt WRN NO RTC backup battery is flat
History file
InteliDrive-Lite stores a record of each important event into the history file. The history file seats 117
records. When the history file is full, the oldest records are removed.
Hint:
To force history download in LiteEdit (direct, modem or Internet) open History window and select
History | Read history command.
Record structure
Abbreviation Historical value
Num Number of historical event
Reason Event specification
Date Date of historical event in format DD/MM/YY
Time Time of historical event in format HH:MM:SS
RPM Engine speed
UBat Battery voltage
OilP ID-Lite Analog input 1 value ( default Oil pressure)
EngT ID-Lite Analog input 2 value ( default Water temperature)
FLvl ID-Lite Analog input 3 value ( default Fuel level)
AIM1 Plug-in Analog input 1 value
AIM2 Plug-in Analog input 2 value
