ComAp InteliDrive Lite User Manual

ID–Lite-2.0 User guide, ©ComAp – January 2011 92
ID-Lite-2.0 User guide.pdf
Max total current per module: 2,5A
IL-NT IO1 (optional card)
Plug-in into ID-Lite controller EXTENSION MODULE port.
Number of Analog outputs: 4
Analog output range: 0 to +VBatt ±1V
Number of binary inputs: 4 (equal to ID-Lite CU)
IGL-RA15 (optional Remote Annunciator)
Power supply
Voltage supply 8-36V DC
Consumption 0,35-0,1A (+1A max horn output)
Depend on supply voltage
Operating conditions
Operating temperature -20..+70
o
C
Storage temperature -40..+80
o
C
Protection front panel IP65
Dimensions and weight
Dimensions 180x120x55mm
Weight 950g
Horn output
Maximum current 1 A
Maximum switching voltage 36 VDC
