Values read from ECU
Value name Short name Dimension
Type Frame name
EngOil Filter Diff.Press
OilDiffPres bar ANA DD
Amber Warning Lamp AmberWrnLamp - BIN DM1
Malfunction Lamp MalfunctLamp - BIN DM1
Protect Lamp ProtectLamp - BIN DM1
Red Stop Lamp RedStopLamp - BIN DM1
Engine speed RPM RPM ANA EEC1
Engine Oil Pressure EngOil Press bar ANA EFLP1
Coolant Temp Coolant Temp °C ANA ET1
Total Engine Hours EngineHours h ANA HR
Boost Pressure Boost Press bar ANA IC
Intake Manifold Temp Intake Temp °C ANA IC
Cummins MODBUS
When “Cummins-Modbus” option is selected, following values are read from Modbus Register Data
(for QSX15,QSK45, QSK60):
Value name Short name Dimension Type Frame name
Red Shutdown Lamp Red Lamp - BIN 10005
Yellow Warning Lamp Yellow Lamp - BIN 10006
Engine Speed RPM RPM ANA 30001
Coolant Temp Coolant Temp °C ANA 30002
Oil Pressure (psig) Oil Press bar ANA 30003
Oil Pressure (psia) Oil Press bar ANA 30003
Running Time Running Time h ANA 30008
Fuel Rate (UK) Fuel L/h ANA 30018
Fuel Rate (US) Fuel L/h ANA 30018
Intake Manifold Press Intake Press bar ANA 30530
Intake Manifold Temp Intake Temp °C ANA 30531
Diagnostic messages read from ECU
Diagnostic messages are read and displayed in extra ECU Alarm list. For Standard J1939 SPN
(Suspect Parameter Number), FMI (Failure Mode Identifier) and OC (Occurrence Counter) are shown
together with verbal description if available.
One SPN (Suspect Parameter Number) / FMI (Failure Mode Identify) couple describes one fail
information. If FMI is equal to 0 or 1, WRN is displayed in the ECU Alarm list. For any other FMI
values, FLS is displayed.
Detail SPM/FMI code specification see in:
• SAE Truck and Bus Control and Communications Network Standards Manual, SAE HS-1939
Publication
• Or refer to corresponding engine manufacturer’s ECU error codes list.
List of ECU diagnostic codes
Faultcode
Diagnostic code
Faultcode
Diagnostic code Faultcode
Diagnostic code
51 ThrottlePos 158 BattPotential 636 PositionSensor
91 AccelPedalPos 168 ElectricalPot 637 TimingSensor
94 FuelDelPress 172 AirInlet Temp 639 J1939 CAN Bus
97 WaterInFuelInd 174 Fuel Temperat 651 InjectorCyl#1
98 EngineOilLevel 175 EngOil Temp 652 InjectorCyl#2
100 EngOil Press 189 RatedEngSpeed 653 InjectorCyl#3
101 CrankcasePress 190 EngineSpeed 654 InjectorCyl#4
102 Boost Press 231 J1939 Datalink 655 InjectorCyl#5
105 Intake Temp 237 VIN 656 InjectorCyl#6
