ECU CommOK
If the ECU is not communicating and all values from ECU show #### the output is not active. If the
ECU communicates the output is active.
ECU PwrRelay
The output closes at the beginning of prestart and opens if the engine shall be stopped.
ECU YellowLamp
The output copies warning information from ECU.
ECU RedLamp
The output copies shutdown information from ECU.
CtrlHeartBeat
Output signalizes watchdog reset. In a healthy state it blinks at 500ms : 500ms rate. When watchdog
reset occurs, it stops blinking.
ECU CommError
The output is an inversion of binary output ECU CommOK, i.e. the output is closed when ECU is not
communicating and all values from ECU show #####.
BI1..10 – stat
In case the assigned binary input is configured to any control function, the output propagates the state
of the input. BI1..6 are assigned for CU: BI1..6, BI7..10 are assigned for BI7..BI10 of IL-NT IO1
optional card.
BIO8 1..8 Status
In case the assigned binary input of IL-NT BIO8 optional card is configured to any control function, the
output propagates the state of the input.
Timer1
Output activates when Timer1 is active. Simultaneously the engine is started when is in AUT mode.
Timer2
Output activates when Timer2 is active
Glow plugs
The output closes prior to the engine start (Prestart) and opens when Starting RPM speed is reached.
During repeated crank attempts the output is opened.
Conveyor
Binary output of Conveyor function. See Binary input Conveyor.
LoadSwitch
Binary output from Load switch comparator – see Load limit setpoint group.
SpeedSwitch
Binary output from Speed switch comparator – see Regulator setpoint group.
Analog inputs
Three analog inputs are designed for resistive sensors only.
